1.5 CBM Mixer Truck | self loading concrete mixer truck | Prices for Small Automatic-Loading Concrete Mixer Trucks

No.TL15CBM
The self loading flat mouth concrete mixer truck is an advanced construction machine that combines loading, batching, mixing, transporting, and discharging in one unit. This small concrete mixer truck can automatically load sand, stone, cement, and water, then mix high-quality concrete directly on site. It greatly improves construction efficiency, reduces labor costs, and saves project time.

1.Equipped with a hydraulic bucket, the machine can automatically load sand, gravel, cement, and aggregate without extra loaders. One machine replaces loader + mixer + truck.

2.The flat mouth drum design allows faster concrete discharge and easier cleaning after operation, reducing material residue and maintenance time.
3.Simple mechanical structure, accessible engine layout, and common spare parts make maintenance fast and low-cost.
4.Only one operator is needed. Lower fuel consumption, less manpower, and no need for external batching plants help save money every day.
  • 1.5 CBM Mixer Truck |  self loading concrete mixer truck | Prices for Small Automatic-Loading Concrete Mixer Trucks
  • 1.5 CBM Mixer Truck |  self loading concrete mixer truck | Prices for Small Automatic-Loading Concrete Mixer Trucks
  • 1.5 CBM Mixer Truck |  self loading concrete mixer truck | Prices for Small Automatic-Loading Concrete Mixer Trucks
  • 1.5 CBM Mixer Truck |  self loading concrete mixer truck | Prices for Small Automatic-Loading Concrete Mixer Trucks
  • 1.5 CBM Mixer Truck |  self loading concrete mixer truck | Prices for Small Automatic-Loading Concrete Mixer Trucks
  • 1.5 CBM Mixer Truck |  self loading concrete mixer truck | Prices for Small Automatic-Loading Concrete Mixer Trucks
  • Description

  • More informations



Performance Paramete

 Model TLST-1.5m³
Engine model XICHAI490ZY
Rated power / rotational speed 42kw/2400
Power 58hp
 Engine Capacity 3.76L
 Agitator capacity 1.5m³
Concrete Output 8-9m³/h
Rotational speed 30~34r/min
Driving form Four-wheel Drive Model
Bucket capacity 0.35m³
 Tire model 23.5/70-17
Rated load capacity 3450KG
Overall weight 3800KG
Dimension(Long * Breadth * High) 4900*1800*2750mm

 This small concrete mixer truck can automatically load sand, stone, cement, and water, then mix high-quality concrete directly on site. It greatly improves construction efficiency, reduces labor costs, and saves project time.

The Self Loading Flat Mouth Concrete Mixer Truck is a highly efficient construction machine that combines loading, batching, mixing, transportation, and unloading in one unit. It is specially designed for small and medium construction projects that require fresh concrete anytime and anywhere.

This small concrete mixer truck can automatically load sand, gravel, cement, and water through its hydraulic bucket system, then mix the materials evenly inside the drum. After mixing, the concrete can be transported directly to the construction area and discharged quickly, greatly improving working efficiency.

The flat mouth drum design provides faster unloading speed, easier cleaning, and lower material residue compared with traditional mixer drums. It is ideal for road construction, house building, farms, bridges, rural projects, and remote job sites without ready-mix concrete plants.

Powered by a reliable diesel engine, this self loading cement mixer truck offers strong climbing ability, flexible movement, low fuel consumption, and simple maintenance. One operator can complete the whole process, helping reduce labor cost and save project time.

This machine is widely exported to Africa, Southeast Asia, Central Asia, and South America, making it a cost-effective solution for contractors, builders, and rental companies.

usage scenario:

Road Construction ,House Building Projects,Farm & Rural Projects,Bridge & Drainage Works,Remote Construction Sites,Rental Business
itis suitable for construction work in various special environments,crowded urban areas,and remoteareas.it can be used for road maintenance of concrete pavements,industrial parks,    construction sites,mines,logging sites,etc.it can save time and effort in working environments.

Self-loading concrete mobile cement mixer is the combination of concrete mixer truck and cement mixer, which can automatically feed,measure, mix and discharge concrete mixture. Equipped with a powerful engine and 4 wheel steering, the self loading concrete mixeris just like a small car and the operator can drive it to where it needs to go. Self loading mobile concrete mixer is very convenient for loading material, such as cement, aggregate, stone. The raw material is scattered in the construction site.

Core Advantages
1.Equipped with a hydraulic bucket, the machine can automatically load sand, gravel, cement, and aggregate without extra loaders. One machine replaces loader + mixer + truck.

2.The flat mouth drum design allows faster concrete discharge and easier cleaning after operation, reducing material residue and maintenance time.
3.Simple mechanical structure, accessible engine layout, and common spare parts make maintenance fast and low-cost.
4.Only one operator is needed. Lower fuel consumption, less manpower, and no need for external batching plants help save money every day.

The Self Loading Mixer Truck in Africa is becoming one of the most demanded machines because:

  • Strong infrastructure growth
  • Increasing labor cost
  • Insufficient ready-mix concrete stations
  • Many rural and remote projects
  • Need fast mobile concrete production
  • Affordable investment with quick return

FAQ

Q1: What is the capacity of this self loading concrete mixer truck?

A: We offer different models such as 1.2CBM,1.5CBM. 1.8CBM, 2.2CBM, 3.5CBM and more.

Q2: Can one operator run the machine?

A: Yes. One skilled operator can complete loading, mixing, driving and unloading.

Q3: Is it suitable for rough roads?

A: Yes. The machine has strong tires and powerful driving ability for uneven roads.

Q4: How long does it take to mix one batch?

A: Usually 12-15 minutes depending on materials and operator skill.

Q5: Do you provide overseas shipping?

A: Yes. We support container loading, sea shipping, and export documents worldwide.

Buyers Show



Overseas company




Production  Environment





Global Services

Mature and Perfect Service Systerm



Certificaitons

What Payment terms would you accept?

Normally we accept L/C, or /T 30% down payment,balance to be paid against BL copy and loadingpictures.

What is your delivery time?

For standard machine, the delivery time is Within 25-35 days after receiving the down payment.

What services would you offer if I buy from you?

Our trained Professional service team offershigh-quality in-time service in a very friendly way.For a good customer experience,the content of pre-sales includes the recommendationbased on the right products on physical condition.All you have to do is to inform us of your needs.

Do you accept small order?

Yes. the MOQ is 1 units for most of products.For very small handling equipments,we can check case by case.
